CFP-CrossClip

Register

Variation

  • Description

The CableFixPro CrossClip is designed for routing cables transversely across a panel string and guiding them to a central cable tray on box-design solar panel frames. It clips onto the short side of the frame, allowing cables to be fed across the string and slide upward toward the tray — a clean, secure connection purpose-built for this application.

A dedicated addition to the CableFixPro range, fully compatible with existing BirdBlocker box-design clips and bird-proofing systems. Holds up to 4 cables per clip (based on 6 mm²); multiple clips can be used per panel side for larger volumes.

Specifications

Material: Stainless spring steel wire, NS coated (EN 10270-3:01, 1.4310 DIN 10088-1, BS EN 10088-3:2014)
Cable capacity: Up to 4 × 6 mm² cables per clip
Warranty: 10 years
Pack size: 50 clips
Height: 30-35 mm

Variants

  • CFP-CrossClip 8–13 mm wide (SKU: CF-BoxClip-50cc W8-13xH30-35 50, EAN: 8785253123134)
  • CFP-CrossClip 14–18 mm wide (SKU: CF-BoxClip-50cc W14-18xH30-35 50, EAN: 8785253123127)

Installation: Mount on the short side of box-design panel frames. Multiple cable strains can be slid and tensioned in accordance with applicable norms and regulations.
